Zhaga-D4i New Generations Connect Interface
Zhaga socket JL-700
2A-sensor short cap
XE-02A Sensor Shorting Cap is a NEMA interface protection device comply with UL773 and ANSIC136.41 standard ,it is twist-lock installed in street lamp, courtyard lamp and other lighting lamps.It can replace the light control or single-lamp controller when there is no need to control the lighting fixtures. The short-circuit cap is a device that keeps the lamp on constantly. It has the characteristics of large over-current and wide application voltage. It is widely used in power grid standards all over the world. Comply with UL773 & ANSI C136.41-2013 Fireproof and UV resistant, suitable for various outdoor lamps and lanterns Convenient / reliable / durable twist-lock connection
XE-03B05B07B Fixed Photocontrol Receptacle
XE-03B/05B/07B NEMA (three-wire/five-wire/seven-wire) socket is a connector socket comply with ANSI C136.41 standard, providing reliable outdoor electromechanical connections. It can be twisted and locked to match outdoor street lamp, courtyard lamp and other lighting controllers.In order to solve the problem of how to install the light control at the best angle position, the products we developed can be fixed by screws after the street light installer chooses the best orientation. It is simple, convenient and fast to connect the external circuit of lamps fixtures. Comply with ANSI C136.41-2013 Fireproof and UV resistant, suitable for various outdoor lamps fixtures. Convenient / reliable / durable twist-lock connection Preset wires for easy integration into the lamp The length of the wire can be customized, making it easier to adapt to different lamps
Zhaga socket JL-700
• Standardized interface defined in Zhaga Book 18 • Compact size allowing greater flexibility in luminaire design • Advanced sealing to achieve IP66 with no mounting screws • Scalable solution allows use of Ø40mm photocell and Ø80mm LEX-M in a central management system with the same connection interface • Flexible mounting position, upwards, downwards and sideways facing • Integrated single gasket that seals to both luminaire and module that minimizes assembling time
2B-NEMA photocontrol
XE-02B NEMA photocontrol is a lighting switch control device comply with UL773 and ANSIC136.41 standard,twist-locked installed in street lamp, courtyard lamp and other lighting lamps for automatic switch control. This type of photo control can detect the ambient brightness to control the switch function of lamps. Wide voltage input, widely used in power grid standards around the world. In addition, it has different switching brightness threshold and delay characteristics, which can avoid the influence caused by lights or lightning at night. Comply with UL773 & ANSI C136.41-2013 Fireproof and UV resistant, suitable for various outdoor lamps and lanterns Convenient / reliable / durable twist-lock connection Different switch brightness thresholds, delay trigger, reliable and stable Built-in lightning protection devices to effectively protect against surge interference
2A-sensor short cap
XE-02A Sensor Shorting Cap is a NEMA interface protection device comply with UL773 and ANSIC136.41 standard ,it is twist-lock installed in street lamp, courtyard lamp and other lighting lamps.It can replace the light control or single-lamp controller when there is no need to control the lighting fixtures. The short-circuit cap is a device that keeps the lamp on constantly. It has the characteristics of large over-current and wide application voltage. It is widely used in power grid standards all over the world. Comply with UL773 & ANSI C136.41-2013 Fireproof and UV resistant, suitable for various outdoor lamps and lanterns Convenient / reliable / durable twist-lock connection
IP20 slim constant Voltage
IP20 Slim Constant Voltage Input Voltage:100-277Vac Working temperature:-20-+50C Class II design Output Voltage:12/24V for optional Voltage ripple:5% Protection: OCP/SCP/OPP On/off, on/off/Triac dimming/1-10V/DALI dimming models for optional Dimming range:1%-100%
2.IP20 DALI LED Driver
Ripple current:5% ficker free Isolated design Input Voltage:220-240Vac Product range:12-50W Protocol type:DALI DIP Switch Dimming range:1-100% 5 Years warrantee
Non-isolated Linear LED Driver
Class II design Input Voltage:220-240Vac Isolated design Product range:25W-150W Ripple current:5% Protection:OCP/SCP/OPP DIP and NFC+DALI dimming optional
IP67 3 in 1 dimming programmable LED Driver
Product range:42W-600W IP67 universal input 3 in 1 dimming LED Drive;r Isolated power design Class I and Class II Programmable LED Driver ; Input Voltage:90-305Vac Working temperature:-40-+60C Warranty:5 years Ingress protection rating:IP67 All-round protection:Output SCP,OVP,OTP Surge protection：DM5KV,CM10KV 3 in 1 dimming 0-5V/0-10V/PWM/Timer dimming,optional reverse dimming dim to off; CLO 12V/0.2A auxiliary output optional off-line programmable Application:Road lighting,industrial lighting,led horticulture lighting XA means Class I and XB means Class II
IP67 DALI Programmable LED Driver
Product range:60W-600W IP67 universal input DALI Dimming LED Drive;r Isolated power design Class I and Class II Programmable LED Driver ; Input Voltage:90-305Vac Working temperature:-40-+60C Warranty:5 years Ingress protection rating:IP67 All-round protection:Output SCP,OVP,OTP Surge protection：DM5KV,CM10KV 3 in 1 dimming DALI dimming,optional reverse dimming dim to off; CLO 12V/0.3A,24V/0.3A auxiliary output optional Application:Road lighting,industrial lighting,led horticulture lighting MCF means Class I and MCG means Class II
